Ribbon Star Extreme, RGB Outdoor LED Strip Light - UL 24VDC - 118" (3m)

Product Description

SKU: RL-SC-RSX-RGB-10

UL Listed Ribbon Star Extreme RGB is a fully outdoor rated, color changing, LED Strip Light that can be connected in series up to 100ft (30m). Using 2 positive wires (V+) and 3 negative wires (RGB) this strip can achieve longer serial connections than a standard RGB strip light. Be sure to share your positive wires to your RGB control source for the entire strip to work in unison. With a TPU coating (Thermoplastic Polyurethane) Ribbon Star Extreme RGB is IP68 outdoor rated. Making it fully waterproof, submersible, and UV proof. Ribbon Star Extreme RGB LED Strip Light provides a perfect light source for any outdoor and underwater lighting projects. The Strip Light can be cut every 9.5 inches and has multiple connection options that can be waterproofed to suite your projects needs. 7 SMD LEDs per 9.5 inches with a total of 84 LEDs per 3m. At 1.7W per foot, a 3m roll would require at least a 17W, 24VDC power supply. At the maximum series length of 100ft (30m) this ribbon would require at least a 170W 24VDC Constant Voltage power supply. This LED strip light is perfect for any outdoor or underwater lighting project. Use with water features, decks, trailers, boats, RV's, dog kennels, landscaping, business trim, pathway lighting, pools, or any other situation that a fully outdoor proof LED Strip Light is needed. Comes with 10 mounting clips for a permanent mounting solution. Requires a 24VDC Constant Voltage power source. UL Listed for class2 luminaries and fixtures, RoHS and CE approved.

Product Downloads
Click For Product Data Sheet
LED Strip Light Comparison Guide
Click For Electrical Load Calculator
Enter Length: ft
* 1.7 Watts =
0.00 Watts
Product Specifications
SPECIFICATIONS
ModelRibbon Star Extreme, RGB, 118" (3m)
SKURL-SC-RSX-RGB-10
Dimensions118" x 0.6875" x 0.46"H
Connection Type5 Wire RGB(+/+)
LED Chip Type5050
LED Quantity7 SMDs per 9.5 inches
LEDs Per Strip84 SMD LEDs
Input Power24VDC Constant Voltage
Watts1.7W per foot
Beam Angle120°
Lumens34 lm/ft
RatingIP68 Waterproof
Operating Temp-49°~149°F
Max Serial Connection100 Feet
CertificationUL Listed, RoHS, CE
Product Lifetime50,000 Hours
Warranty Period2 Years
Wiring Diagrams
Thumb
Thumb
Thumb
Ribbon Star Extreme RGB Dimensions Ribbon Star Extreme Light Meter
Important Information

This Strip Light can be connected in series up to 100ft (30m). If you are ordering multiple 3m lengths please specify whether to keep one long length or multiple 3m lengths.


Buy
Discount
You Pay
6+
5% off
$95.00
13+
8% off
$92.00
31+
12% off
$88.00
61+
15% off
$85.00
100+
18% off
$82.00
  Reveal - Click the arrow or text to reveal answers.
 CSR - Customer service representatives.
 Purchaser - Verified purchasers of this product.

For B2B or Large Quantity Price Info Click Here

Ribbon Star Extreme RGB Signal Amplifier, 24VDC 5A/CH

SKU: LC-SC-RSX-RGBA     View Product Page
The Ribbon Star Extreme RGB Signal Amplifier is made specifically for use with our Ribbon Star Extreme RGB Outdoor LED Strip Light. If you are installing large amounts of Extreme RGB Strip Light you can use the RGB Extreme Signal Amplifier to extend the RGB control signal once the maximum wattage has been met on the controller. Theoretically you can add an unlimited amount of signal amplifiers in series with your LED Strip lights to add an additional 360W of power per signal amplifier, or 5A per channel. If you are curious how to install a signal amplifier in your RGB LED project see our tutorials page for reference. This product is not intended to be exposed directly to outdoor elements.

Ribbon Star Extreme RGB Signal Amplifier, 24VDC 5A/CH
$54.99

80" Ribbon wire Connector for Ribbon Star Extreme RGB

SKU: RA-SC-RSX-A13     View Product Page
This 83" lead wire connector is made specifically for use with our Ribbon Star Extreme RGB Outdoor LED Strip Light. Use this connector to connect your Extreme Strip to your RGB Controller or 24VDC power source. Four screw down allen bolts make for a simple and secure connection. Use an industrial strength adhesive with a special syringe applicator to make this connector fully water and outdoor proof, as well as fully submersible. See the installation instructions below for reference.

80" Ribbon wire Connector for Ribbon Star Extreme RGB

(3) Ribbon to Ribbon Connector for Ribbon Star Extreme RGB

SKU: RA-SC-RSX-A4-3
This connector is made specifically for use with our Ribbon Star Extreme RGB Outdoor LED Strip Light. Use this connector to easily mate two Extreme RGB LED Strips together. Four screw down allen bolts make for a simple and secure connection. Use a Silicon Glue with special syringe application to make this connector fully water and outdoor proof, as well as fully submersible. See the installation instructions below for reference.

(3) Ribbon to Ribbon Connector for Ribbon Star Extreme RGB

(2) Ribbon wire Ribbon Connector for Ribbon Star Extreme RGB

SKU: RA-SC-RSX-A6-2     View Product Page
This connector is made specifically for use with our Ribbon Star Extreme RGB Outdoor LED Strip Light. With 10" of lead wire between each connector, this can be used to easily mate two Extreme RGB LED Strips together or around a corner. Four screw down allen bolts make for a simple and secure connection. Use an industrial strength Silicon Glue with special syringe application to make this connector fully water and outdoor proof, as well as fully submersible. See the installation instructions below for reference.

(2) Ribbon wire Ribbon Connector for Ribbon Star Extreme RGB

(2) Ribbon wire Connector for Ribbon Star Extreme RGB

SKU: RA-SC-RSX-A8-2     View Product Page
This connector is made specifically for use with our Ribbon Star Extreme RGB Outdoor LED Strip Light. Use this connector to connect your Extreme Strip to your RGB Controller or 24VDC power source. Four screw down allen bolts make for a simple and secure connection. Use a Silicon Glue with special syringe application to make this connector fully water and outdoor proof, as well as fully submersible. See the installation instructions below for reference.

(2) Ribbon wire Connector for Ribbon Star Extreme RGB

(10) Plastic Mounting Clip for Ribbon Star Extreme - RGB

SKU: RA-SC-RSX-A2-10     View Product Page
These are 10 plastic mounting clips made for use with our Ribbon Star Extreme Outdoor RGB LED Strip Lights. Use to secure your LED Strip Lights to any drill-able surface. Click the thumbnail image for clip dimensions.

(10) Plastic Mounting Clip for Ribbon Star Extreme - RGB

(2) End Cap for Ribbon Star Extreme Ribbon RGB

SKU: RA-SC-RSX-A10-2     View Product Page
These are 2 silicon end caps made for use with our Ribbon Star Extreme RGB LED Strip Lights. Use these end caps with an industrial strength adhesive to close and seal your exposed cuts in order to water and outdoor proof your Extreme RGB LED Strip.

(2) End Cap for Ribbon Star Extreme Ribbon RGB
