This Mean Well 1000W, 12VDC LED Power Supply / Transformer, has a 100 - 240AC input and 12VDC output. For dry locations only. Built in short circuit, overload, over voltage, and overheating protection allows for system shutdown upon any of these circumstances. Forced air cooling by built in DC fan allows for cool operating temperatures. Note: The cooling fan runs noisy and may not be suitable for all applications. Working temperatures are -4°F through 140°F. CN3 port allows for remote control of this power supply. It can be used to connect large amounts of LED Lights, LED Light Ribbons, RGB LED lighting and any other 12VDC Constant Voltage LED Lighting products. UL Recognized and CE approved. Can connect up to 900 watts of 12VDC LED lights. Only install face up with sufficient breathing space.
|Model||1000W, 12VDC LED Power Supply|
|Dimensions||10.94"L x 5.0"W x 2.5"H|
|AC Input Voltage||100 - 240VAC|
|DC Output||12VDC / 83.3A|
|Output Watts Max||1000 Watts|
|Warranty Period||1 Year|
(4) Mean Well 1000W - 3000W Power Supply Mounting Brackets with Screws
SKU: PS-MW-MNT2-4 View Product Page
This product is a pack of 4 mounting brackets (MHS026) with 8 screws to mount our Mean Well brand SE & RSP 1000W-3000W power supplies. Use these 4 mounts to secure any of the 12VDC or 24VDC versions of the power supplies mentioned above. If mounting to a vertical surface such as a wall, be sure that the cooling vents are pointed upwards to allow heat to escape the unit. Use these clips to secure our 12VDC or 24VDC 1000W, 1500W, and 3000W indoor transformers to any drillable surface. Sold in sets of 4, 8 mounting screws included.
2 Conductor Direct Burial Wire - 18AWG
SKU: OA-AX-2C View Product Page
This is an 18AWG, 2 conductor stranded copper wire designed for direct burial but can also be used for any indoor or outdoor lighting project using voltage up to 300V RMS. Wires are sold in 10ft and 50ft lengths and will be shipped in one piece when available (1,000ft max). Each stranded pair is coated in a PVC material with a 2 ply water swellable tape and sunlight / moisture resistant PVC jacket to protect from the harshest outdoor elements. This product is designed to be operated in temperatures from -4° ~ 140° F and is not designed for underwater or long term submersed applications. This wire is UL and ETL Listed.
110V Wall Plug Cord Three Prong - 6ft
SKU: LA-EL-CON1 View Product Page
A three prong 110V wall plug power cord for LED Power Supplies. This cord is used to connect a power supply to a 110 volt outlet. 16AWG, 6' long 3 prong, 3 wire. Black wire = Load, White wire = Neutral, Green wire = Ground.
