Dwarf Star 1 Chip LED Backlight Module - White


Product Description

This LED backlight module is a truly unique product. When your project calls for a light with a small form factor and physical imprint look no further than our Dwarf Star 1 module. This product easily conforms to linear, circular or curved layouts with a max serial connection of 20 modules with power from one end, 40 modules if powered at both ends. Don't let the small size of this LED module fool you, it is more than capable to handle all your lighting needs with a max output of 0.24W per LED chip. The Dwarf Star has the ability to be cut at the lead wires between each module for ultimate tailoring to your project. This tiny powerhouse module is ideal for channel letter, halo lighting, sign lighting, accent and cove lighting, under cabinet lighting, hobbyist lighting, model architectural lighting and many more projects! A constant voltage DC power source is needed to power this product. The plastic ABS shell and clear epoxy coating provides limited water-resistance to moisture. Not submersible or UV proof.

Product Downloads
Important Information

The SKU, Price, Module Length and Max Serial Connection for this product has changed, they are now available in 10 & 40 units at a lower price per module! 20 Modules maximum in series or 40 with power from both ends.

Click For Product Data Sheet
Calculate Electrical Load
Enter Modules:
* 0.24 Watts =
0.00 Watts
* Power Supply capacity must be larger than minimum lighting load.
Product Specifications
ModelDwarf Star 1 chip LED Backlight Module - White
Dimensions0.8" x 0.5" x 0.16"H
Connection Type2 Wire (+/-) 20AWG
LEDs Chip Size5050
LEDs Quantity1 LED per Module
Module Spacing4.09" Center to Center
Module Count10 per 3.25 ft
40 per 13 ft
Input Power12VDC
Watts0.24 Watts per module
Beam Angle120°
Lumens22 lm per module
RatingIP65 Water-resistant
Operating Temp-4° ~ 122°F
Max Serial Connection20 Modules
40 Modules Looped Circuit
Lifetime Hours50,000 Hours
CertificationCE, RoHS
Warranty Period1 Year
Wiring Diagrams
ES1 DimensionsModule Light Meter
10 Module String - 3.25ft: MD-HT-ES1-W-10
40 Module String - 13ft: MD-HT-ES1-W-40
You Pay
5% off
8% off
12% off
15% off
Reveal - Click the arrow or text to reveal answers.
CSR - Customer service representatives.
Purchaser - Verified purchasers of this product.
