Mean Well LED Power Supply CV 1500W - 24VDC

SKU: PS-MW-1500-24

Product Description

This industrial grade Mean Well power converter is intended for 100 - 240VAC 20A 50/60Hz input power only, outputting 63A of 24VDC constant voltage power. Built in short circuit, overload, over voltage, and overheating protection allows for system shutdown upon any of these circumstances. Forced air cooling by built in DC fan allows for cool operating temperatures. Note: The cooling fan runs noisy and may not be suitable for all applications. Working temperatures are -4°F through 140°F, dry locations only. Use this power converter to connect large amounts of LED Wall Washers, LED Lights, LED Strips, RGB LED lighting and any other 24VDC Constant Voltage LED Lighting products. UL Recognized and CE approved. We recommend a max load of 90% or connecting no more than 1350 watts of 24VDC LED lights. Only install face up with sufficient breathing space.

Product Downloads
Product Specifications
Model1500W, 24VDC LED Power Supply
Dimensions10.94"L x 5.0"W x 3.29"H
AC Input Voltage100 - 240VAC
DC Output24VDC / 63A
Output Watts Max1500 Watts
Operating Temp-4° ~ 140°F
Warranty Period1 Year
